| Pin range | 5.08x7.62mm |
| Pollution degree | 2 |
| Nominal voltage | 250V |
| Rated impulse voltage | 4 kV |
| Rated current | 10A |
| Connection directions | 90° |
| Cable stripping length | 7mm |
| Solid conductor | 0.25 … 1,5mm² / 23 … 16 AWG |
| Fine-stranded conductor | 0.25 … 1,5mm² / 23 … 16 AWG |
| Fine-stranded conductor with ferule | 0.25 … 1mm² /23 … 18 AWG |
| Material group | IIIa |
| Insulation material | Polyamide (PA6) |
| Flammability class per UL 94 | V0 |
| Pin material | Brass |
| Pin plating | Silver |
| Pin dimensions | 0.5x1mm |
| Drilled pin hole diameter with tolerance | 1.25mm |
| Screw | M3 |
| Recommended max. torque | 0.25Nm |
| Operating temperature | -40 … +100 °C / -40…+ 212 °F |
| Package quantity | 100 |
| Production code | VBDK-D/8 |
| Order code | 34.360 |
| Customs tariff no. | 8536.90.10.00.00 |
| Country of Origin | Turkey |
| No combined products available for this item. |
