7.62mm Female Pluggable Terminal Block – 5 Pins
PCB terminal block with screw connection socket with elevator mechanism5 polesMax. conductor cross section: 2.5mm²-14 AWGPin pitch: 7.62mmRated voltage: 400VRated current: 16A
Color options
Blue
Green
Orange
Black
Gray
Red
Stock color
Blue
Green
Orange
- TECHNICAL SPECIFICATIONS
- COMMERCIAL DATA
- DOWNLOADS
- CERTIFICATES
- COMBINED PRODUCTS
- DATA SHEET
- Taksit Seçenekleri
| Pin range | 7.62mm |
| Pollution degree | 2 |
| Nominal voltage | 400V |
| Rated impulse voltage | 4 kV |
| Rated current | 16A |
| Connection directions | 90° - 180° |
| Cable stripping length | 7mm |
| Solid conductor | 0.25 … 2.5mm² / 23 … 14 AWG |
| Fine-stranded conductor | 0.25 … 2.5mm² / 23 … 14 AWG |
| Fine-stranded conductor with ferule | 0.25 … 1,5mm² / 23 … 16 AWG |
| Material group | IIIa |
| Insulation material | Polyamide (PA6) |
| Flammability class per UL 94 | V0 |
| Pin material | Brass |
| Pin plating | Silver |
| Screw | M2.5 |
| Recommended max. torque | 0.4Nm |
| Operating temperature | -40 … +100 °C / -40…+ 212 °F |
2-12 pins
| Package quantity | 100 |
| Production code | SBDK 7.62-D/5 |
| Order code | 10.705 - 11.705 - 12.705 - 13.705 - 14.705 - 15.705 |
| Customs tariff no. | 8536.90.10.00.00 |
| Country of Origin | Turkey |
| File Name | Size | File Type |
|---|---|---|
| 7-62-sbdk-disi-5.dxf | 195.29KB | DXF |
| 7-62-sbdk-disi-5.xt | 179.49KB | X_T |
| 7-62-sbdk-disi-5.step | 462.07KB | STP |
