| Pin pitch | 7.62mm |
| Pollution degree | 2 |
| Nominal voltage | 250V |
| Rated impulse voltage | 4 kV |
| Rated current | 16A |
| Material group | IIIa |
| Insulation material | Polyamide (PA6) |
| Flammability class per UL 94 | V0 |
| Pin material | Brass |
| Pin plating | Silver plated |
| Pin dimensions | 0.8x1mm |
| Drilled hole diameter with tolerance | 1.3mm |
| Operating temperature | -40 … +100 °C / -40…+ 212 °F |
| Package quantity | 100 |
| Production code | DBK-2/2 |
| Order code | 24.470 |
| Customs tariff no. | 8536.90.10.00.00 |
| Country of Origin | Türkiye |
