5.08mm Modular PCB Terminal Block NO:2 – 2 Pins
Modular PCB terminal block with screw connection with elevator mechanism2 polesMax. conductor cross section: 4mm²-12 AWGPin pitch: 5.08mmRated voltage: 250VRated current: 25A
- TECHNICAL SPECIFICATIONS
- COMMERCIAL DATA
- DOWNLOADS
- CERTIFICATES
- COMBINED PRODUCTS
- DATA SHEET
- Taksit Seçenekleri
| Pin pitch | 5.08mm |
| Pollution degree | 2 |
| Nominal voltage | 250V |
| Rated impulse voltage | 4 kV |
| Rated current | 25A |
| Connection directions | 90° |
| Cable stripping length | 7mm |
| Solid conductor | 0.25 … 4mm² / 23 … 12 AWG |
| Fine-stranded conductor | 0.25 … 4mm² / 23 … 12 AWG |
| Fine-stranded conductor with ferule | 0.25 … 2.5mm² /23 … 14 AWG |
| Material group | IIIa |
| Insulation material | Polyamide (PA6) |
| Flammability class per UL 94 | V0 |
| Pin material | Brass |
| Pin plating | Silver |
| Pin dimensions | 0.9x1mm |
| Drilled pin hole diameter with tolerance | 1.5mm |
| Screw | M2.5 |
| Recommended max. torque | 0.4Nm |
| Operating temperature | -40 … +100 °C / -40…+ 212 °F |
2-3 pins
| Package quantity | 200 |
| Production code | MBDK 5.08-2/2 |
| Order code | 20.340 - 21.340 - 22.340 - 23.340 - 24.340 - 25.340 |
| Customs tariff no. | 8536.90.10.00.00 |
| Country of Origin | Türkiye |
| File Name | Size | File Type |
|---|---|---|
| 5-08-mbdk-no-2-2.dxf | 153.64KB | DXF |
| 5-08-mbdk-no-2-2.step | 181.06KB | STP |
| 5-08-mbdk-no-2-2.xt | 74.32KB | X_T |
| No combined products available for this item. |
